1500186

Overview

The Phoenix Contact part number 1500186 corresponds to the QP 1,5/ 1-L GNYE plug component. This single-position terminal block features a 5.2 mm pitch and is designed for quick connection methods. It supports rigid and flexible wire cross-sections ranging from 0.25 mm² to 1.5 mm² (AWG 24-16). The unit has a rated voltage of 500 V, a nominal current of 17.5 A, and a rated surge voltage of 6 kV. Constructed from PA insulation material with UL 94 V0 flammability rating, it operates within an overvoltage category III and pollution degree 3 environment.

Feature Summary

• Features a left-side plug housing without a safety pin, allowing for easy integration into COMBI connector systems.
• Utilizes a quick connection technology compatible with PVC and PE insulated wires for efficient assembly.
• Complies with IEC 61984 standards for switchless capacity connectors used in load-free or voltage-free conditions.

Applications

• Industrial control cabinet wiring
• Signal distribution panels
• Automation system interconnections

Procurement Notes

Verify the specific ordering suffix matches the required color coding and housing configuration. Confirm that the application environment aligns with the specified overvoltage category and pollution degree ratings. Ensure compatibility with mating COMBI components before finalizing procurement orders.

Selection Notes

Select this component when a single-position, quick-connect solution is required for low-voltage signal or power distribution. Consider the 5.2 mm pitch dimension for panel layout constraints. Verify that the 17.5 A current carrying capacity meets the circuit requirements for the connected conductor size.

Part Context

This component belongs to the Phoenix Contact COMBICON Terminals S product line. It serves as a modular plug element designed to interface with corresponding socket bases. The series provides standardized connectivity solutions for industrial automation and control applications requiring reliable electrical connections.

Replacement Considerations

Consult official Phoenix Contact cross-reference tools for verified substitute part numbers. Generic equivalents may not match the specific IEC 61984 compliance or mechanical dimensions required for proper system integration.

FAQ

What is the maximum rated surge voltage for this component?

The rated surge voltage is 6 kV.

Does this plug include a safety pin?

No, this specific model features a left housing without a safety pin.
