1500438

Overview

The Phoenix Contact component with model number 1500438 is identified as a MINI MCR-SL-2-CU-2I. This device functions as a signal converter designed for industrial automation applications. It converts standard process signals into two isolated output signals, facilitating interface tasks between field devices and control systems. The unit supports input signals such as current or voltage from sensors and provides corresponding isolated outputs suitable for PLCs or data acquisition systems.

Feature Summary

• Provides galvanic isolation between input and output circuits to protect sensitive equipment.
• Converts single input signals into two separate, independent output signals.
• Designed for DIN rail mounting in control cabinets for easy integration.

Applications

• Signal conversion in process automation systems
• Isolation of sensor signals for PLC input modules
• Distribution of measurement signals to multiple control units

Procurement Notes

Verify the exact ordering code against official Phoenix Contact catalogs to ensure compatibility with specific voltage ranges and certification requirements. Confirm that the MINI MCR series designation matches the intended isolation and conversion specifications for your application environment.

Selection Notes

Select this component when dual isolated outputs are required from a single source signal. Ensure the input signal type matches the device configuration options available within the MINI MCR-SL series. Check environmental ratings for temperature and humidity if deployed in harsh industrial settings.

Part Context

This part belongs to the MINI MCR series by Phoenix Contact, a line of compact signal conditioners. These devices are engineered for space-saving installation on standard DIN rails. The series typically includes various models for different signal types, offering reliable performance in electrical control engineering.

Replacement Considerations

Consult official Phoenix Contact cross-reference guides for direct replacements. Generic signal converters may not match the specific isolation voltage or form factor. Verify pinout compatibility and mounting dimensions before substituting with other brands.
