150KEVD10ABSW

Overview

The 150KEVD10ABSW is a three-phase power line filter from the TE Connectivity Corcom KEV series. It features a dual-stage design for high-performance EMI suppression and supports a current rating of 150 A at 440 VAC. The unit operates at 50 Hz or 60 Hz with a leakage current of 15 mA. Physical dimensions are 411 mm in length, 230 mm in height, and 160 mm in width. It utilizes chassis mounting with terminal block connections.

Feature Summary

• Dual-stage filtering architecture for enhanced noise attenuation
• High-current capacity suitable for heavy industrial loads
• Robust chassis-mount construction for secure installation

Applications

• Industrial motor drive systems
• Heavy machinery power supplies
• Three-phase manufacturing equipment

Procurement Notes

Verify the specific suffix AB against official datasheets to confirm terminal type and mounting configuration. Confirm availability status as supply conditions vary by region. Ensure the replacement part matches the original electrical ratings and physical footprint requirements for seamless integration into existing enclosures.

Selection Notes

Select this model when high current handling and superior EMI performance are required for three-phase AC systems. The dual-stage topology provides effective noise reduction compared to single-stage alternatives. Verify that the chassis mounting style and terminal block interface align with the system's mechanical constraints and wiring methods.

Part Context

This component belongs to the KEV series of power line filters, designed for demanding industrial environments. The series offers various current ratings and configurations to meet diverse electromagnetic compatibility standards. The KEV series is recognized for its reliability in suppressing conducted interference in high-power applications.

Replacement Considerations

The 150KEVD10AFPW is a documented substitute within the same product family.
