1510634353

Headers, Male Pins Overview

The Molex 1510634353 is a Milli-Grid PCB header connector featuring a 2.00mm pitch and single-row vertical through-hole mounting. It comprises three circuits with male pin contacts designed for wire-to-board applications. The component utilizes liquid crystal polymer insulation and offers gold plating on the mating interface to ensure reliable signal transmission in electronic assemblies.

Headers, Male Pins Feature Summary

• Vertical through-hole mounting configuration for direct PCB integration
• Single-row design with male pin contact style
• Liquid crystal polymer insulation material for structural stability

Headers, Male Pins Applications

• General purpose board-to-wire interconnections
• Consumer electronics assembly
• Industrial control circuitry

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against official Molex documentation to confirm exact plating thickness, pick-and-place cap inclusion, and peg presence. Ensure compatibility with mating receptacles regarding housing dimensions and locking mechanisms before procurement.

Headers, Male Pins Selection Notes

Select this component for applications requiring a 2.00mm pitch vertical header. Confirm that the three-circuit count matches the design requirements. Validate that the through-hole termination method aligns with the manufacturing process capabilities of the target printed circuit board.

Headers, Male Pins Part Context

This part belongs to the Molex Milli-Grid series, which provides compact interconnect solutions for space-constrained designs. The series supports various termination styles and row configurations to accommodate diverse electronic packaging needs across commercial and industrial sectors.

Headers, Male Pins Replacement Considerations

Consult official Molex cross-reference guides for verified substitute part numbers. Do not assume functional interchangeability with generic headers based solely on pitch and row count without verifying mechanical and electrical specifications.
