Product Detailed Parameters
- Description：XTAL OSC XO 25MHZ HCMOS SMD
- Series：1511H
- Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
- Package：Tape & Reel (TR),Strip
- Base Resonator：Crystal
- Type：XO (Standard)
- Frequency：25 MHz
- Function：Enable/Disable
- Output：HCMOS
- Voltage - Supply：1.8V ~ 3.3V
- Frequency Stability：±25ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 85°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：10mA
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：4-SMD, No Lead
- Size / Dimension：0.063" L x 0.047" W (1.60mm x 1.20mm)
- Height - Seated (Max)：0.024" (0.60mm)
- Supplier Device Package：-
Download product information
Overview
The 1511H-25.000KWVDTSTK is a standard crystal oscillator (XO) manufactured by Suzhou Hangjing Elec & Tech Co., Ltd. It operates at a fixed frequency of 25 MHz and utilizes HCMOS output logic levels. The device supports a supply voltage range of 1.8V to 3.3V and includes an enable/disable control function for power management. It is housed in a compact 4-SMD, no-lead package suitable for surface-mount assembly.
Feature Summary
- HCMOS output interface for digital signal compatibility
- Integrated enable and disable control functionality
- Wide supply voltage operation from 1.8V to 3.3V
- Compact 4-SMD no-lead surface mount package
Applications
- Smartphone signal processing circuits
- Tablet computer system clocks
- In-vehicle electronic systems
- GPS module timing references
Procurement Notes
Verify the complete part number including suffixes against official manufacturer documentation to ensure correct voltage, tolerance, and packaging specifications. Confirm that the supplier provides valid traceability and quality certifications consistent with the manufacturer's standards for quartz frequency control components.
Selection Notes
Select this component when a 25 MHz clock source with HCMOS output is required for low-voltage digital applications. Ensure the design accommodates the 1.8V to 3.3V operating range and utilizes the 4-SMD footprint. Validate thermal and electrical requirements against the official datasheet before integration.
Part Context
Suzhou Hangjing Elec & Tech Co., Ltd. specializes in the research, development, and production of quartz frequency control components. The company focuses on precision supply chain management and rigorous testing to support global electronics manufacturers in sectors such as mobile devices, automotive, and satellite communications.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Consult the manufacturer or authorized distributors for direct equivalents or pin-compatible alternatives.
