1511H-26.000J33DTSK

Overview

The 1511H-26.000J33DTSK is a standard HCMOS crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co.,Ltd. It operates at a frequency of 26 MHz and utilizes a 3.3V supply voltage. The device features an enable/disable control function for power management. It is housed in a compact 4-SMD, No Lead package, designed for surface-mount applications.

Feature Summary

• HCMOS output signal compatibility
• Integrated enable and disable functionality
• Compact ceramic seam seal SMD package

Applications

• Network communication systems
• Industrial control equipment
• Consumer electronics devices

Procurement Notes

Verify the specific ordering suffix to confirm voltage levels and pin configurations. Ensure the component matches the required operating temperature range for your application environment. Cross-reference the datasheet specifications with your system design requirements before finalizing procurement orders.

Selection Notes

Select this model when a standard HCMOS output is required for clock generation. Consider the 3.3V supply constraint and the need for an enable/disable feature. Evaluate the physical dimensions of the 4-SMD package against your PCB layout constraints.

Part Context

This part belongs to the 1511H series of quartz frequency controlling units produced by Suzhou Hangjing. The company specializes in research and development of such components, offering various package sizes and precision products for diverse electronic applications.

Replacement Considerations

Check for compatible oscillators from the same manufacturer with identical frequency and package dimensions. Verify that substitute parts support the same HCMOS logic levels and voltage requirements to ensure functional equivalence.
