Product Detailed Parameters
- Description：OSC 1612 50MHz HCMOS 1.8V-3.3V +
- Series：1511H
- Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
- Package：Tape & Reel (TR),Strip
- Base Resonator：Crystal
- Type：XO (Standard)
- Frequency：50 MHz
- Function：Enable/Disable
- Output：HCMOS
- Voltage - Supply：1.8V ~ 3.3V
- Frequency Stability：±300ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 85°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：-
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：4-SMD, No Lead
- Size / Dimension：0.063" L x 0.047" W (1.60mm x 1.20mm)
- Height - Seated (Max)：0.011" (0.28mm)
- Supplier Device Package：-
Download product information
Overview
The 1511H-50.000JWVDTSK is a standard crystal oscillator (XO) manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a frequency of 50 MHz with HCMOS output logic levels. The device supports a supply voltage range of 1.8V to 3.3V and features an enable/disable control function. It is housed in a compact 2016 surface-mount package, suitable for space-constrained electronic designs requiring precise timing signals.
Feature Summary
- HCMOS output interface for digital circuit compatibility
- Integrated enable/disable functionality for power management
- Wide supply voltage operation from 1.8V to 3.3V
- Compact 2016 SMD package design
Applications
- Computing systems requiring clock synchronization
- Communication equipment signal processing
- Industrial control devices
- Medical instrumentation timing circuits
Procurement Notes
Verify the specific ordering suffix JWVDTSK against official manufacturer documentation to confirm exact electrical parameters and packaging specifications. Ensure the component matches the required operating temperature range and load capacitance for the target application. Cross-reference the datasheet for pin configuration and recommended soldering profiles to guarantee reliable integration into the final assembly.
Selection Notes
Select this component when a 50 MHz HCMOS clock source is required within a 2016 footprint. Consider the 1.8V to 3.3V operating range for compatibility with low-voltage digital logic families. The enable/disable feature makes it suitable for battery-powered or power-sensitive applications where dynamic clock gating is necessary. Verify that the package dimensions fit the PCB layout constraints.
Part Context
This model belongs to the standard XO series produced by Suzhou Hangjing Elec&Tech Co., Ltd., founded in 2014. The company specializes in quartz frequency controlling units, including crystals, oscillators, filters, VCXOs, and TCXOs. The 1511H series represents their surface-mount oscillator offerings designed for computing, communication, and industrial applications.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Users should consult the manufacturer directly for qualified alternatives or cross-reference options based on identical electrical and mechanical specifications.
