1521H-80.000GWVDTSK

Overview

The 1521H-80.000GWVDTSK is a standard HCMOS crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a frequency of 80 MHz and supports voltage levels ranging from 1.8V to 3.3V. The component features an enable/disable function for power management. It is housed in a compact 4-SMD, No Lead package, suitable for surface mount applications requiring tight stability.

Feature Summary

• HCMOS output signal compatibility
• Integrated enable and disable control functionality
• Compact surface-mount design

Applications

• General purpose digital clock generation
• Embedded system timing references
• Communication interface synchronization

Procurement Notes

Verify the specific ordering suffix against official manufacturer documentation to ensure correct voltage and tolerance specifications. Confirm that the part number matches the exact frequency requirement of 80 MHz. Cross-reference the package type with PCB footprint designs prior to procurement to avoid assembly errors.

Selection Notes

Select this component when a standard HCMOS output is required for systems operating between 1.8V and 3.3V. Consider the enable/disable feature if power conservation during idle states is necessary. Ensure the application environment falls within the specified operating temperature range for reliable performance.

Part Context

This model belongs to the 1521H series of quartz frequency controlling units produced by Suzhou Hangjing Elec&Tech Co., Ltd. Founded in 2014, the company specializes in research and production of such components. The series is designed for smallest applications with high reliability.

Replacement Considerations

Direct substitutes include other 80MHz HCMOS oscillators in 4-SMD packages with compatible voltage ranges. Verify pinout and electrical characteristics before substitution.
