1522H-12.000G33DWSK

Overview

The 1522H-12.000G33DWSK is a standard crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a frequency of 12 MHz and utilizes HCMOS output logic levels. The device requires a supply voltage of 3.3V and features an enable/disable control function for power management. It is housed in a compact 4-SMD, no lead package, designed for surface-mount assembly on printed circuit boards.

Feature Summary

• HCMOS output logic compatibility
• Integrated enable/disable control functionality
• Surface-mount 4-SMD package design

Applications

• Microcontroller clock sources
• Digital signal processing circuits
• Embedded system timing references

Procurement Notes

Verify the exact part number suffix to ensure correct voltage and package specifications. Confirm that the HCMOS output level matches the receiving input requirements of the target circuit. Check for RoHS compliance status if required by project regulations. Ensure the enable pin is properly configured in the schematic design.

Selection Notes

Select this component when a 12 MHz reference with HCMOS output is required. The 3.3V supply voltage suits modern low-power digital designs. The enable feature allows for dynamic power control. Consider the 4-SMD footprint for space-constrained layouts.

Part Context

This oscillator belongs to the quartz frequency control product line of Suzhou Hangjing Elec&Tech Co., Ltd. The company specializes in R&D and production of crystals and oscillators. This specific model serves as a timing source for electronic devices requiring precise frequency generation.

Replacement Considerations

No public substitute part numbers are documented. Verify compatibility with existing footprints and electrical parameters before considering alternative components from other manufacturers.
