1522H-24.000J33DTSNK

Overview

The 1522H-24.000J33DTSNK is a quartz crystal oscillator manufactured by Suzhou Hangjing Elec & Tech Co., Ltd. It operates at a frequency of 24 MHz and utilizes HCMOS output logic levels. The device supports an operating voltage range of 1.8V to 3.3V and includes enable/disable functionality for power management. It is housed in a compact 4-SMD, No Lead surface-mount package and supplied in Tape & Reel (TR) format.

Feature Summary

• HCMOS output interface for digital signal processing
• Integrated enable and disable control capability
• Compact 4-SMD no-lead surface-mount design

Applications

• Smartphone signal processing circuits
• In-vehicle electronic systems
• GPS navigation modules

Procurement Notes

Verify the specific ordering suffix J33DTSNK against official manufacturer documentation to confirm voltage, tolerance, and packaging specifications. Ensure compatibility with the target PCB footprint and reflow soldering profile. Confirm that the supplier provides valid traceability documents matching the component origin.

Selection Notes

Select this component when a 24 MHz clock source with HCMOS compatibility is required within a 1.8V to 3.3V supply range. The enable/disable feature allows for dynamic power control in battery-operated devices. Evaluate thermal stability requirements against the available ppm options to ensure system timing accuracy.

Part Context

This oscillator belongs to the 1522H series from Suzhou Hangjing Elec & Tech, which focuses on quartz frequency control components. The series is designed for applications requiring precision timing in consumer electronics and communication devices. The manufacturer emphasizes low failure rates and consistent quality through rigorous testing protocols.

FAQ

What is the output logic type of the 1522H-24.000J33DTSNK?

The component uses HCMOS output logic levels.

Does this oscillator support power control features?

Yes, it includes enable and disable functionality to manage power consumption.
