Overview

The Phoenix Contact 1525286 is a PCB terminal block from the COMBICON Terminals S product line, specifically model ICC25-TP1,5/5L3,5-5015. It features a 3.5 mm pitch and five positions in a single row. The component utilizes push-in spring connection technology for conductor attachment and wave soldering for mounting to the printed circuit board. It has a nominal current rating of 8 A and supports a nominal voltage of 150 V under category III/2 conditions. The housing is blue with linear pinning layout.

Feature Summary

• Push-in spring connection mechanism for tool-free conductor insertion
• Wave soldering mounting type for secure PCB attachment
• Single row configuration with five potentials

Applications

• Industrial control cabinet wiring
• Signal distribution in automation systems
• General purpose PCB interconnection

Procurement Notes

Verify the specific ordering suffix matches the required pitch and number of positions. Confirm that the push-in spring connection method aligns with the assembly process requirements. Ensure the rated voltage and current specifications meet the circuit design constraints before procurement.

Selection Notes

Select this component when a compact terminal block with a 3.5 mm pitch is required. The push-in connection offers faster assembly compared to screw terminals. Verify compatibility with the intended wire cross-section range and ensure the wave soldering profile suits the manufacturing setup.

Part Context

This part belongs to the ICC..-TP1,5/..L3,5 product family within the COMBICON Terminals S series. It is designed for high-density applications requiring reliable electrical connections on printed circuit boards. The series is characterized by its standardized dimensions and robust connection technology suitable for industrial environments.

Replacement Considerations

Check for identical pitch (3.5 mm) and position count (5). Ensure the connection method (push-in spring) and mounting type (wave soldering) are compatible substitutes. Verify that the nominal current and voltage ratings meet or exceed the original specifications.

FAQ

What is the connection method for this terminal block?

The terminal block uses a push-in spring connection method for attaching conductors.

How many positions does this component have?

It has five positions arranged in a single row.
