1532C-100.000K33DTSTK

$3.20

Description：XTAL OSC XO 100MHZ HCSL SMD
Series：1532C
Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
Package：Tape & Reel (TR),Strip

SKU:70329d252b2f Category: Oscillators Brand: Suzhou Hangjing Elec&Tech Co.,Ltd

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：XTAL OSC XO 100MHZ HCSL SMD
Series：1532C
Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
Package：Tape & Reel (TR),Strip
Base Resonator：Crystal
Type：XO (Standard)
Frequency：100 MHz
Function：Enable/Disable
Output：HCSL
Voltage - Supply：3.3V
Frequency Stability：±25ppm
Absolute Pull Range (APR)：-
Operating Temperature：-40°C ~ 85°C
Spread Spectrum Bandwidth：-
Current - Supply (Max)：10mA
Ratings：-
Mounting Type：Surface Mount
Package / Case：6-SMD, No Lead
Size / Dimension：0.126" L x 0.098" W (3.20mm x 2.50mm)
Height - Seated (Max)：0.031" (0.80mm)
Supplier Device Package：-

Download product information

1532C-100.000K33DTSTK

Overview

The 1532C-100.000K33DTSTK is a standard crystal oscillator (XO) manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a nominal frequency of 100 MHz and utilizes HCSL output logic for signal integrity in high-speed digital applications. The device is designed for surface-mount assembly using a 6-SMD, no-lead package configuration. It supports a supply voltage of 3.3V and includes enable/disable functionality for power management control. The component is engineered to provide tight stability and high reliability suitable for compact electronic designs.

Feature Summary

HCSL output logic interface
Enable/disable control capability
Surface-mount 6-SMD no-lead package

Applications

High-speed digital circuit reference frequency generation
Compact electronic system timing sources
IC and component synchronization

Procurement Notes

Verify the specific ordering suffix against official manufacturer documentation to ensure correct package type and electrical specifications. Confirm that the HCSL output and 3.3V supply requirements align with the target circuit design before procurement. Ensure compatibility with the 6-SMD no-lead footprint during PCB layout validation.

Selection Notes

Select this component when HCSL signaling is required for noise immunity in high-speed interfaces. The 3.3V supply voltage must match the system power rail. Consider the 6-SMD no-lead package constraints for board space limitations. Verify that the 100 MHz frequency meets the precise timing needs of the application.

Part Context

This part belongs to the quartz frequency controlling units produced by Suzhou Hangjing Elec&Tech Co., Ltd., founded in 2014. The company specializes in research, development, and production of quartz crystals and oscillators. The product line emphasizes tight stability and reliability for smallest applications, adhering to ISO 9001:2015 quality standards.
