1532C-24.000J33DTK

Overview

The 1532C-24.000J33DTK is a 24 MHz HCSL crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates on a 3.3V supply and features Enable/Disable functionality. The device utilizes a 6-SMD, No Lead surface mount package. Frequency stability is rated at ±20ppm, with an operating temperature range of -40°C to 85°C.

Feature Summary

• HCSL output interface for high-speed signaling compatibility
• Integrated enable/disable control capability
• Surface mount design suitable for compact applications

Applications

• High-speed digital communication systems
• Consumer electronics requiring precise timing
• Network equipment clocking

Procurement Notes

Verify the complete part number including suffixes against official manufacturer documentation to ensure correct voltage, frequency, and package specifications. Confirm that the supplier provides traceability to original manufacturing data sheets. Ensure compliance with RoHS standards if required by your specific application environment.

Selection Notes

Select this component when HCSL logic levels are required for signal integrity in 24 MHz applications. The ±20ppm stability suits general-purpose timing needs within the industrial temperature range. Consider the 6-SMD footprint for PCB space constraints and automated assembly processes.

Part Context

This oscillator belongs to the 1532C series from Suzhou Hangjing, which focuses on quartz frequency control units. The company specializes in R&D and production of crystals and oscillators for automotive and consumer markets.

Replacement Considerations

Check for direct substitutes with identical HCSL outputs and 3.3V operation. Verify pinout compatibility for the 6-SMD no-lead package before swapping components.
