Product Detailed Parameters
- Description：OSC, 3225, HCSL, 25MHZ, 30ppm, 3
- Series：1532C
- Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
- Package：Tape & Reel (TR)
- Base Resonator：Crystal
- Type：XO (Standard)
- Frequency：25 MHz
- Function：Enable/Disable
- Output：HCSL
- Voltage - Supply：3.3V
- Frequency Stability：±30ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 85°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：-
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：SMD 3.2mm x 2.5mm
- Size / Dimension：0.126" L x 0.098" W (3.20mm x 2.50mm)
- Height - Seated (Max)：0.039" (1.00mm)
- Supplier Device Package：-
Download product information
Overview
The 1532C-25.000J33DTSK is a standard crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a nominal frequency of 25 MHz and utilizes HCSL output signaling. The device is designed for surface-mount applications, featuring a compact 6-SMD, No Lead package configuration. It supports a supply voltage of 3.3V and includes an Enable/Disable control function for power management. This component is engineered to provide stable frequency generation suitable for digital circuits requiring precise timing references.
Feature Summary
- HCSL differential output signaling for noise immunity
- Integrated enable/disable control capability
- Compact surface-mount form factor
Applications
- Digital signal processing systems
- Communication equipment clocking
- General-purpose timing reference circuits
Procurement Notes
Verify the specific ordering suffix against the manufacturer's current datasheet to ensure compatibility with required voltage levels and output types. Confirm that the 6-SMD package dimensions align with the target PCB footprint. Check for any recent updates to the RoHS compliance status or lead-free specifications before finalizing procurement orders.
Selection Notes
Select this model when HCSL interface compatibility is required for the receiving logic gates. Ensure the system design accommodates the 3.3V supply rail and provides necessary control signals for the enable pin. Consider the thermal characteristics of the SMD package if high-density mounting is planned within the assembly.
Part Context
This part belongs to the standard crystal oscillator series produced by Suzhou Hangjing Elec&Tech Co., Ltd. The company specializes in quartz frequency controlling units, focusing on research and development of precision timing components. The 1532C series represents their surface-mount offerings designed for modern electronic assemblies.
Replacement Considerations
Consult official cross-reference lists from Suzhou Hangjing for direct equivalents. Verify electrical parameters such as load capacitance and drive level before substituting with generic alternatives to maintain signal integrity.
