Product Detailed Parameters
- Description：XTAL OSC XO 100MHZ HCSL SMD
- Series：1532C6
- Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
- Package：Tape & Reel (TR),Strip
- Base Resonator：Crystal
- Type：XO (Standard)
- Frequency：100 MHz
- Function：Enable/Disable
- Output：HCSL
- Voltage - Supply：3.3V
- Frequency Stability：±10ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 85°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：40mA
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：6-SMD, No Lead
- Size / Dimension：0.126" L x 0.098" W (3.20mm x 2.50mm)
- Height - Seated (Max)：0.043" (1.10mm)
- Supplier Device Package：-
Download product information
Overview
The 1532C6-100000K33DTSTK is a surface-mount crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a fundamental frequency of 100.0000 MHz and utilizes HCSL (High-Speed Current-Mode Logic) output signaling for high-speed digital applications. The component is housed in a standard SMD package, designed for integration into compact electronic circuits requiring precise timing references. It complies with RoHS standards, ensuring environmental safety for modern manufacturing processes.
Feature Summary
- HCSL output interface optimized for high-speed signal integrity
- Surface-mount design suitable for automated assembly
- RoHS compliant construction
Applications
- High-speed data communication interfaces
- Industrial control systems
- IT infrastructure equipment
Procurement Notes
Verify the exact part number against official manufacturer documentation to ensure correct HCSL output configuration and frequency tolerance. Confirm package dimensions and pinout compatibility with the target PCB layout prior to procurement. Ensure supply chain sources provide genuine components with valid traceability records.
Selection Notes
Select this component when a 100 MHz clock source with HCSL signaling is required for noise-sensitive high-speed designs. Evaluate thermal stability requirements against the specified operating temperature range. Consider the SMD form factor for space-constrained board layouts where traditional through-hole oscillators are unsuitable.
Part Context
Suzhou Hangjing Elec&Tech Co., Ltd specializes in quartz frequency control units, including oscillators and resonators. This model belongs to their portfolio of precision timing devices designed for industrial and commercial electronics. The company focuses on integrated research, development, and production of high-stability frequency components.
Replacement Considerations
Cross-reference with other 100 MHz HCSL surface-mount oscillators from different manufacturers if supply constraints exist. Verify that substitute parts match the specific HCSL voltage levels and drive strength requirements to maintain signal integrity in the application circuit.
