1532D-25.000J33DTK

Overview

The 1532D-25.000J33DTK is a standard differential oscillator manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a nominal frequency of 25 MHz and utilizes LVDS output waveform technology for signal transmission. The component is designed for operation with a supply voltage of 3.3V and features an enable/disable control function. It is housed in a compact 6-SMD, no lead package with dimensions of 3.2mm x 2.5mm. This device is engineered to provide stable frequency generation suitable for various electronic applications requiring precise timing signals.

Feature Summary

• Utilizes LVDS output waveform for high-speed differential signaling
• Incorporates enable and disable control functionality for power management
• Designed for surface mount assembly in compact electronic systems

Applications

• Digital communication equipment requiring precise clock signals
• Data processing systems utilizing differential input interfaces
• Consumer electronics with space-constrained design requirements

Procurement Notes

Verify the complete part number including suffixes such as 'DTK' against official manufacturer documentation to ensure correct packaging and tape specifications. Confirm that the required operating temperature range and load conditions align with the specific datasheet parameters provided by Suzhou Hangjing Elec&Tech Co., Ltd. before finalizing procurement orders.

Selection Notes

Select this component when a 25 MHz differential clock source is required with LVDS compatibility. Ensure the system design supports the 3.3V supply voltage and accommodates the enable/disable control logic. Consider the physical footprint constraints of the 3.2mm x 2.5mm SMD package during PCB layout planning to ensure proper soldering and thermal performance.

Part Context

This model belongs to the 1532D series of quartz frequency controlling units produced by Suzhou Hangjing Elec&Tech Co., Ltd. Founded in 2014, the company specializes in the research, development, and production of quartz-based components. The 1532D series represents their standard differential oscillator line, focusing on providing reliable frequency control solutions for modern electronic devices.

Replacement Considerations

Direct substitutes include other 25 MHz LVDS oscillators from different manufacturers with identical pin configurations and electrical characteristics. Verify compatibility regarding drive strength and output swing levels when replacing with alternative brands to ensure signal integrity in the target application circuit.
