Product Detailed Parameters
- Description：3225 13.5MHz HCMOS 3.3V +/-30ppm
- Series：1532H
- Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
- Package：Tape & Reel (TR),Strip
- Base Resonator：Crystal
- Type：XO (Standard)
- Frequency：13.5 MHz
- Function：Enable/Disable
- Output：HCMOS
- Voltage - Supply：3.3V
- Frequency Stability：±300ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 85°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：-
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：SMD 3.2mm x 2.5mm
- Size / Dimension：0.126" L x 0.098" W (3.20mm x 2.50mm)
- Height - Seated (Max)：0.039" (1.00mm)
- Supplier Device Package：-
Download product information
Overview
The 1532H-13.500J33DTSK is a 13.5 MHz crystal oscillator (XO) manufactured by Suzhou Hangjing Elec & Tech Co., Ltd. It utilizes HCMOS output logic and operates at a supply voltage of 3.3V. The device features an enable/disable control function for power management. It is housed in a compact 4-SMD, No Lead package, designed for surface-mount applications requiring precise frequency control.
Feature Summary
- HCMOS output logic for standard digital interfacing
- Integrated enable/disable functionality for power optimization
- Surface-mount 4-SMD no-lead package design
Applications
- Smartphones and tablets
- Satellite communications systems
- In-vehicle electronic systems
- GPS modules
Procurement Notes
Verify the manufacturer designation as Suzhou Hangjing Elec & Tech Co., Ltd. Confirm the specific part number 1532H-13.500J33DTSK matches the required 13.5 MHz frequency and 3.3V HCMOS specifications. Ensure the 4-SMD no-lead package type aligns with PCB layout requirements. Cross-reference datasheet parameters for stability and operating temperature ranges before finalizing procurement.
Selection Notes
Select this component when a 13.5 MHz reference clock is required for HCMOS-compatible circuits. The enable/disable feature supports power-sensitive designs. The small 4-SMD footprint is suitable for space-constrained portable devices. Verify that the 3.3V supply voltage matches the system's power rail. Consider the operating temperature range if deployed in automotive or industrial environments.
Part Context
Suzhou Hangjing Elec & Tech Co., Ltd. specializes in quartz frequency control components, including oscillators and crystals. This model belongs to their standard XO series, targeting applications in consumer electronics and communications. The company focuses on precision supply chain management and quality testing to ensure low failure rates for global electronics manufacturers.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Direct replacement requires matching the 13.5 MHz frequency, HCMOS output, 3.3V supply, and 4-SMD package dimensions. Consult official distributor databases for cross-reference data.
