1532H-16.000J33DTSK

Overview

The 1532H-16.000J33DTSK is a standard crystal oscillator (XO) manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a frequency of 16 MHz and utilizes HCMOS output levels. The device functions with a 3.3V supply voltage and includes enable/disable control capabilities. It is housed in a compact 4-SMD, no-lead package suitable for surface-mount applications.

Feature Summary

• HCMOS output interface
• Enable/disable control functionality
• Surface-mount SMD package

Applications

• General electronic timing circuits
• Embedded system clock sources
• Consumer electronics devices

Procurement Notes

Verify the manufacturer part number against official Suzhou Hangjing documentation to ensure authenticity. Confirm that the specific suffix matches the required electrical specifications and package type. Request datasheets directly from authorized distributors or the manufacturer to validate technical parameters before procurement.

Selection Notes

Select this component when a 16 MHz HCMOS clock signal is required for digital logic circuits. Ensure the design supports the 3.3V operating voltage and accommodates the 4-SMD footprint. Verify that the enable/disable feature aligns with power management requirements in the target application.

Part Context

This oscillator belongs to the 1532H series from Suzhou Hangjing, which specializes in quartz frequency controlling units. The series offers various frequencies and packages, providing standardized timing solutions for industrial and consumer electronics markets.

Replacement Considerations

No public substitute part numbers are confirmed in available documentation. Cross-reference with other 16 MHz HCMOS oscillators in 4-SMD packages only if electrical compatibility is verified through official datasheets.
