Product Detailed Parameters
- Description：XTAL OSC XO 27MHZ HCMOS SMD
- Series：1532H
- Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
- Package：Tape & Reel (TR),Strip
- Base Resonator：Crystal
- Type：XO (Standard)
- Frequency：27 MHz
- Function：Enable/Disable
- Output：HCMOS
- Voltage - Supply：3.3V
- Frequency Stability：±30ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 85°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：10mA
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：4-SMD, No Lead
- Size / Dimension：0.126" L x 0.098" W (3.20mm x 2.50mm)
- Height - Seated (Max)：0.031" (0.80mm)
- Supplier Device Package：4-VDFN (3.2x2.5)
Download product information
Overview
The 1532H-27.000J33DTSTK is a standard HCMOS crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co.,Ltd. It operates at a frequency of 27.000 MHz and utilizes a 3.3V supply voltage. The component features Enable/Disable functionality for power management control. It is housed in a compact 4-SMD, No Lead package, suitable for surface-mount assembly. This oscillator provides stable clock signals for digital circuits requiring precise timing synchronization.
Feature Summary
- Standard HCMOS output waveform compatibility
- Integrated enable and disable control capability
- Compact surface-mount package design
Applications
- Computing systems
- Communication devices
- Industrial control equipment
Procurement Notes
Verify the exact part number against official manufacturer documentation to ensure correct specifications. Confirm that the ordering suffix matches the required voltage and package type. Check for any specific handling requirements during procurement. Ensure the supplier provides valid traceability information. Validate the component authenticity through authorized channels before purchase.
Selection Notes
Select this component when a 27.000 MHz clock source with HCMOS outputs is required. Consider the 3.3V operating voltage for system compatibility. Evaluate the need for enable/disable functionality for power efficiency. Assess the physical space constraints for the 4-SMD package. Verify temperature range requirements against application needs.
Part Context
This oscillator belongs to the 1532H series from Suzhou Hangjing, designed for quartz frequency control applications. The series offers solutions for computing, communication, and industrial sectors. Hangjing specializes in research and production of quartz units, providing robust components for various electronic areas. The company focuses on low failure rates and professional support for its product lines.
Replacement Considerations
Consult official substitution lists for compatible alternatives. Verify electrical parameters such as frequency, voltage, and output type match exactly. Ensure package dimensions are compatible with existing footprints. Check manufacturer recommendations for direct replacements to maintain performance integrity.
