Product Detailed Parameters
- Description：oscillator,3225,4 pads, HCOMS, 1
- Series：1532H
- Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
- Package：Tape & Reel (TR),Strip
- Base Resonator：Crystal
- Type：XO (Standard)
- Frequency：11.2896 MHz
- Function：Enable/Disable
- Output：HCMOS
- Voltage - Supply：3.3V
- Frequency Stability：±30ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 85°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：-
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：SMD 3.2mm x 2.5mm
- Size / Dimension：0.126" L x 0.098" W (3.20mm x 2.50mm)
- Height - Seated (Max)：0.039" (1.00mm)
- Supplier Device Package：-
Download product information
Overview
The 1532H4-11.2896J33DTSK is a crystal oscillator manufactured by Suzhou Hangjing Elec & Tech Co., Ltd. It operates at a frequency of 11.2896 MHz and utilizes HCMOS output logic. The device functions with a supply voltage of 3.3V and includes an enable/disable control feature. It is housed in a compact 4-SMD, no-lead package, suitable for surface-mount applications requiring precise timing signals.
Feature Summary
- Integrates enable and disable functionality for power management
- Utilizes HCMOS output logic for signal compatibility
- Designed for surface-mount assembly via 4-SMD no-lead package
Applications
- Smartphone timing circuits
- Tablet communication modules
- In-vehicle system synchronization
- GPS receiver clocking
Procurement Notes
Verify the manufacturer part number against official Suzhou Hangjing documentation to confirm the specific enable/disable pin configuration and HCMOS logic levels. Ensure the 3.3V supply requirement aligns with the target circuit design. Confirm the 4-SMD no-lead package dimensions match the PCB footprint specifications before finalizing procurement orders.
Selection Notes
Select this component when a 11.2896 MHz reference clock with HCMOS output is required. The 3.3V operating voltage must be compatible with the host system's power rails. The enable/disable feature allows for dynamic power control. Verify that the 4-SMD no-lead package fits within the available board space constraints.
Part Context
This oscillator belongs to the 1532H4 series from Suzhou Hangjing Elec & Tech, which focuses on quartz frequency control components. The company specializes in R&D and production of crystals and oscillators for consumer electronics and automotive applications. This specific model provides a standard frequency output for digital signal processing tasks.
Replacement Considerations
Cross-reference with other 11.2896 MHz HCMOS oscillators in 4-SMD packages. Ensure voltage levels and enable pin logic polarity are identical. Verify package outline drawings for mechanical compatibility. Check datasheets for equivalent electrical performance metrics.
