Overview

The Phoenix Contact IB IL 24 PSDO 8-PAC (Order No. 1544302) is a safety digital output module within the Inline product family, designed for integration into SafetyBridge, INTERBUS-Safety, and PROFIsafe systems. It features an Inline local bus interface with switchable transmission speeds of 500 kBit/s or 2 MBit/s. The module provides eight safety digital outputs configured as four dual-channel or eight single-channel outputs. It utilizes spring-loaded push-in connections for wiring and operates on a 24 V DC supply voltage.

Feature Summary

• Supports multiple safety protocols including SafetyBridge, INTERBUS-Safety, and PROFIsafe
• Configurable transmission speed via hardware switch
• Flexible output configuration for dual or single channel safety applications

Applications

• Safety-related digital output control in industrial automation
• Integration into SafetyBridge network architectures
• Implementation within INTERBUS-Safety system topologies
• Deployment in PROFIsafe compliant fieldbus networks

Procurement Notes

Verify that the specific order number 1544302 corresponds to the IB IL 24 PSDO 8-PAC model when sourcing components. Confirm compatibility with the existing Inline base unit and ensure the selected transmission speed setting matches the station's bus requirements. Check for any regulatory compliance updates regarding CRA regulations mentioned in recent documentation.

Selection Notes

Select this module when a compact solution for safety digital outputs is required within the Inline ecosystem. Ensure the application demands support for SafetyBridge, INTERBUS-Safety, or PROFIsafe protocols. Verify that the available space accommodates the module dimensions and that the power supply meets the 24 V DC requirement for reliable operation.

Part Context

This component belongs to the Phoenix Contact Inline series, which offers modular I/O solutions for distributed automation. The IB IL 24 PSDO 8-PAC specifically addresses safety-critical output tasks, allowing engineers to implement redundant or standard safety logic without requiring separate safety PLCs for every output point.

FAQ

Can the transmission speed be adjusted after installation?

Yes, the transmission speed can be set to either 500 kBit/s or 2 MBit/s using a switch on the module.

What is the maximum number of safety outputs provided?

The module provides up to eight safety digital outputs when configured in single-channel mode.
