1549643

Overview

Phoenix Contact part number 1549643 is a heavy duty power connector insert, specifically the HC-CME-DD-71-M model. It features a male pin configuration with 71+PE positions. The component supports crimp termination for wire cross-sections ranging from 0.14 mm² to 2.5 mm² (14 AWG max). Rated for 250 V and 10 A, it utilizes UL94 V-0 flammability rated materials. Designed for control cabinet connections, this conductor connector ensures reliable electrical interfacing within industrial environments.

Feature Summary

• Male pin contact gender for secure mating
• Crimp termination method for robust wire attachment
• Integrated PE (polyethylene) grounding positions
• UL94 V-0 flammability rating for safety compliance

Applications

• Control cabinet wiring connections
• Industrial heavy duty power distribution
• Machine tool electrical interfaces

Procurement Notes

Verify the exact part number 1549643 against official Phoenix Contact documentation to confirm specifications. Ensure compatibility with corresponding housing units. Check for updated datasheets regarding material certifications and environmental ratings before integration into final designs.

Selection Notes

Select this insert when a male pin configuration with 71 signal contacts plus ground is required. Confirm that the mating housing supports the HC-CME series. Verify wire gauge requirements fall within the 0.14 mm² to 2.5 mm² range for proper crimping performance.

Part Context

This component belongs to the Phoenix Contact HC-CME series of heavy duty connector inserts. These inserts are designed to be mounted into standardized heavy duty housings, providing modular connectivity solutions for high-current industrial applications while maintaining compact form factors.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided source data. Consult Phoenix Contact technical support for equivalent alternatives if this specific configuration is unavailable.
