Overview

Phoenix Contact part number 1550584 is a heavy-duty connector contact insert designed for the HC-DCC series. It features a socket configuration with 4 positions plus protective earth (PE). The unit utilizes crimp termination and supports conductors ranging from 6 mm² to 16 mm². Rated for 690 V voltage and 70 A current, it employs size DCC06 contacts measuring 6 mm. This component facilitates reliable power supply connections in industrial environments.

Feature Summary

• Provides secure electrical connection via crimp termination method
• Integrates dedicated protective earth position alongside signal/power contacts
• Engineered for high-current applications up to 70 amperes

Applications

• Power supply distribution in data centers
• Industrial machine building interconnects
• Heavy-duty equipment control panels

Procurement Notes

Verify that the selected housing corresponds to the HC-DCC series to ensure mechanical compatibility. Confirm conductor cross-section falls within the 6 mm² to 16 mm² range for proper crimping. Ensure the mating environment supports the specified 690 V rating. Check for required accessories such as sealing elements if IP protection is needed beyond the base housing rating.

Selection Notes

Select this insert when a 4-position plus ground socket is required for the HC-DCC system. Consider the 70 A current capacity for main power lines. Verify that the cable preparation tools support the 6-16 mm² wire range. Compare against male inserts if polarity reversal is necessary for the specific circuit design.

Part Context

This component belongs to the Phoenix Contact HC-DCC heavy-duty connector family. These connectors are standardized for robust industrial use, offering modular insertion options. The DCC06 size designation indicates the contact interface dimensions compatible with specific housing shells in the HEAVYCON product line.

Replacement Considerations

Direct substitutes include other Phoenix Contact HC-DCC series socket inserts with identical pin counts and current ratings. Cross-brand replacements require matching the DCC06 interface standard and verifying voltage/current derating curves for equivalent performance.
