1553C6-125000J33DTSTK

Overview

The 1553C6-125000J33DTSTK is a crystal oscillator (XO) manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a frequency of 125.000 MHz and utilizes HCSL output logic. The device is housed in a surface-mount SMD package with six no-lead pins. It functions with a supply voltage of 3.3V and includes an enable/disable control feature for power management.

Feature Summary

• HCSL output logic interface
• Enable/disable functionality
• Surface-mount construction

Applications

• Communication systems
• Network equipment
• Consumer electronics

Procurement Notes

Verify the exact package dimensions and pinout configuration against the official datasheet before integration. Confirm RoHS compliance status and lead-free soldering requirements to ensure adherence to environmental regulations and assembly processes. Check for any specific handling instructions regarding electrostatic discharge sensitivity during procurement and storage.

Selection Notes

Select this component when a 125 MHz clock signal with HCSL compatibility is required. Ensure the design supports the 3.3V operating voltage and accommodates the enable pin logic levels. Verify that the PCB layout allows for the specified SMD footprint and thermal dissipation characteristics appropriate for the application environment.

Part Context

Suzhou Hangjing specializes in quartz frequency control components, including oscillators and resonators. This model belongs to their standard XO line, designed for applications requiring precise timing signals. The company focuses on R&D and manufacturing of these electronic units for various industrial and consumer sectors.

Replacement Considerations

Direct substitutes must match the 125 MHz frequency, HCSL output type, 3.3V supply, and 6-SMD no-lead package. Verify electrical parameters and pin assignments before swapping manufacturers.
