Product Detailed Parameters
- Description：5032 212.5MHz LVDS 3.3V +/-30ppm
- Series：1553D
- Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
- Package：Tape & Reel (TR),Strip
- Base Resonator：Crystal
- Type：XO (Standard)
- Frequency：212.5 MHz
- Function：Enable/Disable
- Output：LVDS
- Voltage - Supply：3.3V
- Frequency Stability：±300ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 85°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：-
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：6-SMD, No Lead
- Size / Dimension：0.197" L x 0.126" W (5.00mm x 3.20mm)
- Height - Seated (Max)：0.051" (1.30mm)
Download product information
Overview
The 1553D-212.500J33DTK is a 212.5 MHz LVDS crystal oscillator manufactured by Suzhou Hangjing Elec & Tech Co., Ltd. It operates on a 3.3V supply voltage and features ±20ppm frequency stability across an operating temperature range of -40°C to 85°C. The component utilizes a 6-SMD, No Lead surface mount package with Enable/Disable functionality for power management.
Feature Summary
- Supports LVDS output signaling for high-speed digital applications
- Includes enable/disable control capability for efficient power management
- Designed for surface mount integration in compact electronic assemblies
Applications
- General signal processing systems requiring precise timing
- Embedded electronics utilizing standard LVDS interfaces
- Industrial equipment operating within specified temperature ranges
Procurement Notes
Verify the complete part number including suffixes against official manufacturer documentation to ensure correct voltage, package, and performance specifications. Confirm that the supplier provides genuine components from Suzhou Hangjing Elec & Tech Co., Ltd. to guarantee compliance with the stated electrical parameters and quality standards.
Selection Notes
Select this oscillator when a 212.5 MHz LVDS clock source is required with ±20ppm stability. Ensure the design supports 3.3V operation and accommodates the 6-SMD no-lead footprint. Validate that the application environment remains within the -40°C to 85°C operational temperature limits for reliable performance.
Part Context
Suzhou Hangjing Elec & Tech Co., Ltd. specializes in quartz frequency control components, including oscillators and resonators. This model represents their standard XO line, designed for precision timing in consumer and industrial electronics. The company focuses on R&D and production of frequency control units since its establishment in 2014.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided data. Cross-reference with other 212.5 MHz LVDS oscillators only if pinout and electrical specifications match exactly.
