1553D150000K33DTK

Overview

The 1553D150000K33DTK is a quartz crystal oscillator manufactured by Suzhou Hangjing Elec & Tech Co., Ltd. It operates at a frequency of 150 MHz and utilizes LVDS output signaling for high-speed data transmission. The device is housed in a 6-SMD, No Lead surface-mount package, ensuring compact integration into modern electronic circuits. It functions with a supply voltage of 3.3V and includes an Enable/Disable control feature for power management flexibility. This standard XO component is designed to provide precise timing signals for digital systems requiring stable clock sources.

Feature Summary

• Provides stable 150 MHz clock signal using LVDS interface technology
• Features enable/disable functionality for efficient power control
• Utilizes compact 6-SMD no-lead surface mount packaging

Applications

• High-speed FPGA timing applications
• Data handling systems requiring precise synchronization
• Consumer electronics and mobile devices

Procurement Notes

Verify the manufacturer part number against official Suzhou Hangjing documentation to ensure authenticity. Confirm that the specific LVDS output type and 3.3V operating voltage align with your circuit design requirements. Check for RoHS compliance status if environmental regulations apply to your production process. Ensure the 6-SMD package dimensions match your PCB footprint specifications before finalizing procurement orders.

Selection Notes

Select this component when a 150 MHz clock source with LVDS outputs is required for noise-immune signal integrity. The 3.3V supply voltage makes it suitable for standard logic families. Consider the enable/disable pin for system-level power optimization. The surface-mount form factor supports automated assembly processes. Evaluate thermal performance and load capacitance requirements against your specific application constraints.

Part Context

Suzhou Hangjing Elec & Tech Co., Ltd. specializes in quartz frequency control components, including oscillators and crystals. Founded in 2014, the company focuses on R&D and production for global electronics markets. This oscillator belongs to their standard XO line, serving as a critical signal-processing element for smartphones, tablets, and satellite communications. The brand emphasizes precision supply chains and rigorous testing to maintain low failure rates across diverse sectors.

Replacement Considerations

No public substitute part numbers are confirmed in available documentation.
