Product Detailed Parameters
- Description：XTAL OSC XO 108MHZ LVDS SMD
- Series：1553D6
- Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
- Package：Tape & Reel (TR),Strip
- Base Resonator：Crystal
- Type：XO (Standard)
- Frequency：108 MHz
- Function：Enable/Disable
- Output：LVDS
- Voltage - Supply：3.3V
- Frequency Stability：±10ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 85°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：100mA
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：6-SMD, No Lead
- Size / Dimension：0.197" L x 0.126" W (5.00mm x 3.20mm)
- Height - Seated (Max)：0.047" (1.20mm)
- Supplier Device Package：-
Download product information
Overview
The 1553D6-108000K33DTSTK is a quartz crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a frequency of 108 MHz and utilizes LVDS output signaling. The device is housed in a surface-mount package with dimensions of 5032. It functions within a supply voltage range of 3.3V and supports an operating temperature range from -40°C to +85°C. This component is designed for high-speed digital applications requiring stable clock signals.
Feature Summary
- LVDS output interface for low-noise signal transmission
- Surface-mount construction for automated assembly
- Wide industrial temperature range support
Applications
- High-speed data communication systems
- Industrial control equipment
- IT infrastructure networking devices
Procurement Notes
Verify the exact package footprint and pinout against the official datasheet before integration. Confirm that the LVDS load requirements match the target circuit design. Ensure the supply voltage tolerance aligns with the system power rails. Check for any specific reflow soldering profile recommendations to maintain component integrity during assembly processes.
Selection Notes
Select this component when LVDS signaling is required for noise immunity in high-frequency environments. The 5032 package size offers a balance between performance and board space constraints. Consider the 3.3V supply requirement and industrial temperature range suitability for the specific application environment. Verify compatibility with the target clock distribution network.
Part Context
This part belongs to the HCIO series oscillators produced by Suzhou Hangjing Elec&Tech Co., Ltd. The company specializes in quartz frequency controlling units, including crystals, oscillators, filters, VCXOs, and TCXOs. The 1553D6 series represents their standard oscillator offerings designed for computing, communication, and industrial applications.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Direct replacement requires matching LVDS output type, 108 MHz frequency, 5032 package, and 3.3V operation.
