1553H-10.000K33DTSK

$0.81

Description：XTAL OSC XO 10MHZ 3.3V HCMOS SMD
Series：1553H
Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
Package：Tape & Reel (TR),Strip

SKU:238cb801b4d9 Category: Oscillators Brand: Suzhou Hangjing Elec&Tech Co.,Ltd

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：XTAL OSC XO 10MHZ 3.3V HCMOS SMD
Series：1553H
Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
Package：Tape & Reel (TR),Strip
Base Resonator：Crystal
Type：XO (Standard)
Frequency：10 MHz
Function：Enable/Disable
Output：HCMOS
Voltage - Supply：3.3V
Frequency Stability：±25ppm
Absolute Pull Range (APR)：-
Operating Temperature：-40°C ~ 85°C
Spread Spectrum Bandwidth：-
Current - Supply (Max)：-
Ratings：-
Mounting Type：Surface Mount
Package / Case：4-SMD, No Lead
Size / Dimension：0.197" L x 0.126" W (5.00mm x 3.20mm)
Height - Seated (Max)：0.051" (1.30mm)
Supplier Device Package：-

Download product information

1553H-10.000K33DTSK

Overview

The 1553H-10.000K33DTSK is a quartz crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a frequency of 10 MHz with a supply voltage of 3.3 V. The output interface is HCMOS, and the device supports Enable/Disable functionality. It is housed in a 4-SMD, No Lead surface-mount package and is supplied in Tape & Reel (TR) packaging.

Feature Summary

HCMOS output interface for digital signal compatibility
Integrated enable/disable control capability
Surface-mount design for automated assembly

Applications

Smartphone signal processing
In-vehicle system timing
GPS module clock generation

Procurement Notes

Verify the exact datasheet specifications directly from the manufacturer before integration. Confirm that the 4-SMD No Lead package dimensions match your PCB footprint requirements. Ensure the 3.3V HCMOS logic levels are compatible with your target circuit's input thresholds to prevent signal integrity issues during operation.

Selection Notes

Select this component when a precise 10 MHz reference clock is required for digital systems. The HCMOS output ensures direct interfacing with standard logic circuits without additional buffering. The enable/disable feature allows for power management strategies in battery-operated devices like smartphones and GPS units where standby current reduction is critical.

Part Context

Suzhou Hangjing Elec&Tech Co., Ltd specializes in quartz frequency controlling units, including crystals, oscillators, and filters. This model belongs to their XTAL OSC XO series, designed for applications requiring stable frequency control in consumer electronics and communication devices.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Cross-referencing with other manufacturers requires independent verification of electrical parameters and pinout compatibility.
