1553H-16.000KWVDTSTK

Overview

The 1553H-16.000KWVDTSTK is a 16 MHz crystal oscillator (XO) manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It utilizes HCMOS output logic and operates within a supply voltage range of 1.8V to 3.3V. The device features an enable/disable control function for power management. It is housed in a compact 4-SMD, No Lead package with dimensions of 3.20mm x 3.20mm. This standard frequency control unit is designed for applications requiring precise timing signals.

Feature Summary

• HCMOS output interface for digital logic compatibility
• Integrated enable/disable control functionality
• Compact 4-SMD surface-mount package design

Applications

• Consumer Electronics
• Automotive Systems
• Industrial Equipment

Procurement Notes

Verify the specific ordering suffix against official documentation to ensure correct voltage and package specifications. Confirm that the component matches the required HCMOS logic level and physical footprint for your circuit design. Check manufacturer guidelines for handling and storage conditions to maintain quartz integrity during assembly.

Selection Notes

Select this component when a 16 MHz standard clock signal is required with low-voltage operation capabilities. Ensure the target application supports HCMOS output levels and requires an enable pin for power optimization. Verify that the 4-SMD package size fits within the available PCB real estate constraints.

Part Context

This oscillator belongs to the 1553H series from Suzhou Hangjing, which specializes in quartz frequency controlling units. The company focuses on research and production of resonators and oscillators for various industries. This specific model represents a standard XO variant optimized for modern electronic systems requiring reliable timing sources.

Replacement Considerations

Consult official substitution lists for compatible parts. Direct replacements must match the 16 MHz frequency, HCMOS output type, and 4-SMD package dimensions. Verify electrical parameters such as supply voltage range before integrating alternative components.
