1553H-33.333333KWVDTSTK

Overview

The 1553H-33.333333KWVDTSTK is a crystal oscillator (XO) manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a frequency of 33.333333 MHz and supports supply voltages ranging from 1.8 V to 3.3 V. The component utilizes HCMOS output logic and is housed in a 4-SMD, no-lead package with dimensions of 5032. This device functions as a precision timing source for electronic circuits requiring stable clock signals.

Feature Summary

• Generates precise clock signals using quartz frequency control technology
• Supports enable and disable functionality for power management
• Utilizes HCMOS output logic for digital circuit integration

Applications

• Smartphone signal processing
• Satellite communication systems
• In-vehicle electronic systems
• GPS navigation modules

Procurement Notes

Verify the manufacturer part number against official documentation to ensure authenticity. Confirm that the specific ordering suffix matches the required voltage range and package type. Check for any regional distribution restrictions or compliance certifications relevant to the target market before finalizing procurement orders.

Selection Notes

Select this component when a 33.333333 MHz clock signal is required within a 1.8 V to 3.3 V operating range. Ensure the design accommodates the 5032 surface-mount package footprint. Verify compatibility with HCMOS logic levels and confirm that the enable/disable feature aligns with system power management requirements.

Part Context

Suzhou Hangjing Elec&Tech Co., Ltd. specializes in the research, development, and production of quartz frequency controlling units. The company focuses on providing precision supply chain solutions for components used in consumer electronics, automotive systems, and telecommunications equipment.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Consult official manufacturer channels for cross-reference data.
