1556148

Overview

The Phoenix Contact 1556148 is a PCB terminal block designed for secure electrical connections in industrial control environments. It features a nominal current rating of 24 A and supports a voltage rating up to 800 V. The component utilizes a screw connection method with a pitch of 7.62 mm, accommodating conductors ranging from 0.5 mm² to 2.5 mm². Constructed with UL94V-0 rated polycarbonate housing, it ensures flame retardancy and high dielectric strength. The unit includes a color-coded marking field for identification and is compatible with standard DIN rail mounting systems when used with appropriate accessories.

Feature Summary

• Screw connection mechanism provides reliable mechanical clamping force for stranded and solid wires.
• Color-coded marking field allows for clear circuit identification and maintenance traceability.
• Flame-retardant polycarbonate housing meets UL94V-0 safety standards for industrial applications.

Applications

• Industrial control cabinet wiring
• Signal distribution panels
• Power supply interconnections

Procurement Notes

Verify the specific ordering code against the manufacturer's official datasheet to ensure compatibility with required conductor cross-sections and voltage ratings. Confirm that the packaging quantity matches project requirements, as bulk orders may differ from single-unit purchases. Check for any recent regulatory updates or RoHS compliance statements directly from Phoenix Contact documentation before finalizing procurement decisions.

Selection Notes

Select this component based on its 7.62 mm pitch and 24 A current capacity relative to the circuit design requirements. Ensure the operating environment temperature range aligns with the specified limits of the polycarbonate housing. Consider the need for auxiliary components such as bridging elements or end brackets if multiple units are installed adjacent to each other in dense panel layouts.

Part Context

This terminal block belongs to Phoenix Contact's standard series of PCB-mounted connectors, widely used in automation and machinery manufacturing. It serves as a critical interface between printed circuit boards and external wiring harnesses. The design prioritizes ease of installation and long-term reliability under vibration and thermal cycling conditions common in industrial settings.

Replacement Considerations

No direct public substitute part numbers are confirmed for this specific model. Users should consult Phoenix Contact technical support for equivalent alternatives with matching pitch and current ratings.

FAQ

What is the maximum conductor cross-section supported by this terminal block?

The terminal block supports conductors with a cross-section ranging from 0.5 mm² to 2.5 mm².

Is the housing material flame retardant?

Yes, the housing is made of polycarbonate rated UL94V-0 for flame retardancy.
