Overview

Phoenix Contact part number 1556164 is a sensor/actuator cable from the SAC-5P series. It features an M12 female connector (A-coded, 5-position) on one end and a free wire end on the other. The cable length is 3 meters. It utilizes 5 x 0.25 mm² conductors with a cross-section of 0.25 mm². The outer jacket is made of PUR (polyurethane) in yellow color. The assembly is shielded and rated for IP67 protection. It supports a nominal voltage of 24 V DC and a current rating of 4 A.

Feature Summary

• Features an M12 male connector interface for secure field connections.
• Constructed with a durable PUR jacket for resistance to oils and mechanical stress.
• Includes integrated shielding to ensure signal integrity in industrial environments.
• Designed for direct connection to sensors and actuators without additional mating plugs.

Applications

• Connecting industrial sensors to control systems
• Actuator wiring in automation machinery
• Signal transmission in harsh industrial environments

Procurement Notes

Verify the specific connector coding (A-code vs B-code) and pin configuration against the system requirements. Confirm that the PUR jacket material meets the chemical resistance needs of the installation environment. Ensure the IP67 rating is sufficient for the exposure conditions. Check compatibility with existing M12 socket interfaces.

Selection Notes

Select this model when a pre-assembled M12 solution is required to reduce wiring time. The 3-meter length provides flexibility for standard cabinet-to-field distances. The yellow color aids in visual identification within complex wiring schemes. Consider the bending radius specifications during routing planning.

Part Context

This component belongs to the SAC-5P product line, which specializes in single-pair Ethernet and sensor/actuator cabling solutions. The series is designed for high reliability in automated manufacturing settings. Phoenix Contact integrates these cables into broader IIoT connectivity portfolios.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with alternative lengths or connector types from the same manufacturer if exact matches are unavailable.
