1575307

Overview

The Phoenix Contact LPTA 6/11-7,5-ZF is a fixed PCB terminal block designed for high-current applications. It features an 11-position configuration with a 7.5 mm pitch and supports wire cross-sections up to 6 mm². The component has a nominal current rating of 41 A and a rated voltage of 1000 V (III/2). Constructed with polyamide housing and tin-plated copper contacts, it utilizes wave soldering for installation. The operating temperature range spans from -40°C to 105°C, ensuring reliability in demanding industrial environments.

Feature Summary

• High current capacity of 41 A for robust power distribution
• Supports large wire cross-sections up to 6 mm²
• Insulation material provides thermal stability across wide temperature ranges

Applications

• Industrial control cabinet wiring
• Power supply connections
• Heavy-duty signal distribution

Procurement Notes

Verify the specific ordering suffix ZF against official Phoenix Contact documentation to confirm the presence of marking fields or specific contact plating variations. Ensure the requested part number matches the exact pin count and pitch requirements for your PCB layout. Cross-reference the rated voltage category III/2 with system insulation requirements before procurement.

Selection Notes

Select this component when high current carrying capability and large wire acceptance are required. The 7.5 mm pitch allows for substantial conductor sizes compared to standard terminal blocks. Verify that the wave soldering mounting method aligns with your assembly process capabilities and thermal profile constraints.

Part Context

This part belongs to the LPTA 6 series of PCB terminal blocks from Phoenix Contact. The series is characterized by its ability to handle significant currents and wire gauges. The specific model indicates an 11-position arrangement within this high-performance family of connectors.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Direct replacement requires matching the 7.5 mm pitch, 11 positions, and 41 A current rating precisely.
