Product Detailed Parameters
- Description：Oscillator,7050, LVDS, 125MHz, 2
- Series：1575D
- Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
- Package：Tape & Reel (TR),Strip
- Base Resonator：Crystal
- Type：XO (Standard)
- Frequency：125 MHz
- Function：Enable/Disable
- Output：LVDS
- Voltage - Supply：3.3V
- Frequency Stability：±25ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 85°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：-
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：-
- Size / Dimension：0.276" L x 0.197" W (7.00mm x 5.00mm)
- Height - Seated (Max)：0.039" (1.00mm)
- Supplier Device Package：-
Download product information
Overview
The 1575D-125.000K33DTSK is a quartz crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a frequency of 125 MHz and utilizes LVDS output signaling for high-speed data transmission stability. The device is powered by a 3.3V supply voltage and features an enable/disable control function to manage power consumption. It is housed in a compact 6-SMD, no-lead surface-mount package, suitable for automated assembly processes in dense circuit board layouts.
Feature Summary
- LVDS output interface ensures signal integrity and noise immunity
- Integrated enable/disable functionality for power management
- Surface-mount design optimized for high-density PCB applications
Applications
- High-speed digital communication systems
- Data acquisition and processing circuits
- Industrial automation control boards
Procurement Notes
Verify the exact part number suffix against official manufacturer documentation to confirm pinout compatibility and electrical specifications. Ensure that the procurement source provides valid traceability records. Cross-reference the datasheet for thermal characteristics and operating temperature ranges before integration into final products.
Selection Notes
Select this component when LVDS signaling is required for 125 MHz clock distribution. Consider the 3.3V supply constraint and the need for active enable control. Evaluate the 6-SMD package dimensions against available board space. Confirm load capacitance requirements match the target system design.
Part Context
This oscillator belongs to the 1575D series from Suzhou Hangjing, which specializes in quartz frequency control units. The series includes various frequencies and output types. This specific model targets applications needing stable, low-jitter clock sources with differential signaling capabilities.
Replacement Considerations
Direct substitutes must match the 125 MHz frequency, LVDS output type, 3.3V voltage, and 6-SMD package. Verify pin-to-pin compatibility and electrical parameters with alternative manufacturers before substitution.
