1575D-130.000K33DTK

Overview

The 1575D-130.000K33DTK is a standard crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co.,Ltd. It operates at a frequency of 130 MHz and utilizes LVDS output signaling for high-speed data transmission stability. The device functions with a supply voltage of 3.3V and includes an enable/disable control feature for power management flexibility. It is housed in a compact 6-SMD, No Lead package, suitable for surface-mount assembly on printed circuit boards. This component is designed to provide precise clock signals for digital systems requiring low jitter and reliable timing performance.

Feature Summary

• LVDS output interface ensures signal integrity at high frequencies
• Integrated enable/disable pin allows for dynamic power control
• Compact 6-SMD no-lead package facilitates dense board layouts

Applications

• Embedded systems requiring precise clock synchronization
• Industrial automation equipment needing stable timing sources
• Communication modules utilizing high-frequency data links

Procurement Notes

Verify the specific frequency tolerance and load capacitance requirements against your system design before ordering. Confirm that the 3.3V supply voltage aligns with your power rail specifications. Ensure the PCB footprint matches the 6-SMD no-lead package dimensions provided in the official mechanical drawing. Check for any specific environmental ratings if operating in extreme temperatures.

Selection Notes

Select this model when LVDS signaling is required for noise immunity in high-speed digital circuits. Consider the enable/disable functionality if power efficiency during idle states is critical. Evaluate the 130 MHz frequency against the target processor or transceiver input requirements. Compare package size constraints with available board space to ensure compatibility with the 6-SMD form factor.

Part Context

This oscillator belongs to the 1575D series from Suzhou Hangjing, which focuses on standard XO solutions. The series typically offers various frequencies and output types to support diverse electronic applications. Hangjing specializes in quartz frequency control units, providing components for computing, communication, and industrial sectors. The 1575D line emphasizes reliability and compactness for modern electronic designs.

Replacement Considerations

Direct substitutes include other 130 MHz LVDS oscillators in 6-SMD packages with 3.3V operation. Verify pinout compatibility and electrical parameters such as rise/fall times and duty cycle. Cross-reference with similar models like 1575D-100.000K33DTK or 1575D-200.000K33DTK if frequency adjustments are permissible.
