1575D-150.000K33DTSTK

Overview

The 1575D-150.000K33DTSTK is a surface-mount crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a frequency of 150.000 MHz and utilizes LVDS output signaling. The device is housed in a 7050 package format and requires a supply voltage of 3.3V. It offers a frequency stability of ±25 ppm over the operating temperature range of -40°C to +85°C.

Feature Summary

• Provides LVDS differential output signals for high-speed data transmission applications.
• Operates within a standard industrial temperature range of -40°C to +85°C.
• Designed for surface-mount assembly using a compact 7050 package footprint.

Applications

• High-speed serial communication interfaces
• Data acquisition systems requiring precise clocking
• Industrial control equipment

Procurement Notes

Verify the specific suffix codes against official manufacturer documentation to ensure correct output type and tolerance specifications. Confirm that the 7050 package dimensions align with your PCB layout requirements. Check for RoHS compliance status if required by your manufacturing standards. Ensure the 3.3V supply voltage matches your system design constraints before procurement.

Selection Notes

Select this component when LVDS signaling is required for noise immunity in high-frequency applications. The 7050 package size should be evaluated against available board space. Consider the ±25 ppm stability requirement relative to your system's timing budget. Verify compatibility with the 3.3V power domain used in the target circuit design.

Part Context

This part belongs to the 1575D series of oscillators from Suzhou Hangjing, which focuses on quartz frequency control units. The series includes various frequencies and output types tailored for computing and communication sectors. Hangjing specializes in research and production of such components since 2014, targeting industrial and consumer electronics markets.

Replacement Considerations

No public substitute part numbers are confirmed in the provided source material. Cross-referencing with other manufacturers requires independent verification of electrical parameters and pinout compatibility.
