1575H-10.000K33DTSK

Overview

The 1575H-10.000K33DTSK is a standard HCMOS crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co.,Ltd. It operates at a nominal frequency of 10 MHz with a frequency stability of ±25ppm. The device requires a 3.3V supply voltage and features an enable/disable control function. It supports an operating temperature range of -40°C to +85°C. The component utilizes a 4-SMD, No Lead surface mount package, designated as the 7050 form factor.

Feature Summary

• HCMOS output interface for digital logic compatibility
• Integrated enable and disable control functionality
• Surface mount construction in a 4-SMD no lead package

Applications

• Smartphone signal processing circuits
• In-vehicle electronic systems
• GPS module timing references
• Satellite communication equipment

Procurement Notes

Verify the manufacturer designation matches Suzhou Hangjing Elec&Tech Co.,Ltd when sourcing this component. Confirm that the specific ordering suffix corresponds to the 10 MHz frequency and 3.3V enable/disable variant. Ensure the package type aligns with the 4-SMD no lead specification required for the target PCB layout. Cross-reference the frequency stability rating of ±25ppm against system timing requirements before finalizing procurement orders.

Selection Notes

Select this oscillator when a standard HCMOS output is required for digital clocking applications. The 3.3V supply voltage makes it suitable for modern low-power logic families. The wide operating temperature range supports automotive and industrial environments. The enable/disable feature allows for power management strategies in battery-operated devices. Verify that the 7050 footprint fits within the available board space constraints.

Part Context

This component belongs to the 1575H series of quartz frequency control units produced by Suzhou Hangjing Elec&Tech Co.,Ltd. The company specializes in the research, design, production, and sales of quartz oscillators and related components. This series includes various frequency options such as 80 MHz variants, all sharing similar package and interface characteristics. The product line serves global electronics manufacturers requiring precision timing solutions.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
