Product Detailed Parameters
- Description：XTAL OSC XO 12MHz 3.3V HCMOS SMD
- Series：1575H
- Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
- Package：Tape & Reel (TR),Strip
- Base Resonator：Crystal
- Type：XO (Standard)
- Frequency：12 MHz
- Function：Enable/Disable
- Output：HCMOS
- Voltage - Supply：3.3V
- Frequency Stability：±30ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 85°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：30mA
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：4-SMD, No Lead
- Size / Dimension：0.276" L x 0.197" W (7.00mm x 5.00mm)
- Height - Seated (Max)：0.071" (1.80mm)
- Supplier Device Package：-
Download product information
Overview
The 1575H-12.000K33DTSK is a 12 MHz crystal oscillator (XO) manufactured by Suzhou Hangjing Elec&Tech Co.,Ltd. It utilizes HCMOS output logic and operates at a supply voltage of 3.3V. The component features an enable/disable control function, allowing for power management flexibility in circuit designs. It is housed in a compact 4-SMD, no lead surface-mount package, suitable for automated assembly processes.
Feature Summary
- HCMOS output interface for standard digital logic compatibility
- Integrated enable and disable functionality for power control
- Surface-mount package design for PCB integration
Applications
- General-purpose clock signal generation in electronic circuits
- Embedded systems requiring stable frequency references
- Consumer electronics utilizing surface-mount technology
Procurement Notes
Verify the manufacturer part number against official Suzhou Hangjing documentation to ensure authenticity. Confirm that the specific suffix matches the required electrical specifications and package type. Request datasheets directly from authorized sources to validate performance parameters before procurement.
Selection Notes
Select this component when a 12 MHz HCMOS clock source with enable/disable capability is required. Ensure the system design supports 3.3V operation and accommodates the 4-SMD footprint. Verify frequency stability requirements align with the standard specification provided in official documentation.
Part Context
This oscillator belongs to the 1575H series of quartz frequency control units produced by Suzhou Hangjing Elec&Tech Co.,Ltd. The company specializes in the research, development, and production of such components. This specific model represents a standard frequency option within their surface-mount oscillator portfolio.
Replacement Considerations
Cross-reference with other 12 MHz HCMOS oscillators in 4-SMD packages. Verify pinout compatibility and electrical characteristics. Consult official substitution lists from the manufacturer if available.
