1575H-6.000J33DTSK

Overview

The 1575H-6.000J33DTSK is a standard crystal oscillator (XO) manufactured by Suzhou Hangjing Elec&Tech Co.,Ltd. It operates at a fixed frequency of 6 MHz and utilizes HCMOS output logic levels. The device is powered by a 3.3V supply voltage and features an enable/disable control function for power management. It is housed in a compact 4-SMD, No Lead surface-mount package with dimensions of 7.00mm x 5.00mm. The component belongs to the 1575H series and uses a quartz crystal as its base resonator.

Feature Summary

• Supports HCMOS output signal compatibility
• Includes hardware enable and disable functionality
• Utilizes standard quartz crystal resonance technology

Applications

• Digital communication systems requiring precise clock signals
• Embedded microcontroller circuitry
• Consumer electronic devices with surface-mount constraints

Procurement Notes

Verify the specific ordering suffix against official manufacturer documentation to ensure correct voltage and output type alignment. Confirm that the 4-SMD no-lead package matches your PCB footprint requirements. Ensure the HCMOS logic level is compatible with your target interface voltage thresholds before finalizing procurement orders.

Selection Notes

Select this component when a 6 MHz reference clock is required with low-power standby capabilities via the enable pin. The 3.3V operating voltage makes it suitable for modern digital logic families. Consider the physical size constraints of the 7.00mm x 5.00mm package during layout design to ensure adequate soldering area and thermal relief.

Part Context

This oscillator belongs to the 1575H series from Suzhou Hangjing, which specializes in quartz frequency control units. The series offers various frequencies and voltage options within similar SMD packages. This specific model represents a standard configuration optimized for general-purpose timing applications in consumer and industrial electronics.

Replacement Considerations

Direct substitutes must match the 6 MHz frequency, 3.3V supply, HCMOS output, and 4-SMD package dimensions. Verify electrical specifications and pinout compatibility before swapping components to prevent circuit malfunction or damage.
