1575H4-29.4912G33DTSTK

Overview

The 1575H4-29.4912G33DTSTK is a standard crystal oscillator (XO) manufactured by Suzhou Hangjing Elec&Tech Co.,Ltd. It operates at a nominal frequency of 29.4912 MHz and utilizes an HCMOS output interface. The device supports a supply voltage range of 2.5V to 3.3V and features an enable/disable control function. It is housed in a compact 4-SMD, no lead package with a maximum seated height. The component is designed for operation across an extended industrial temperature range of -40°C to +85°C.

Feature Summary

• Integrated enable and disable functionality for power management
• HCMOS logic output interface compatibility
• Industrial-grade wide temperature operational capability

Applications

• Automotive electronics systems
• Network communication equipment
• Intelligent medical devices

Procurement Notes

Verify the exact part number against official manufacturer documentation to ensure correct specifications. Confirm that the HCMOS output type and 3.3V supply requirements align with your system design. Check the operating temperature range limits for your specific application environment. Ensure the 4-SMD package dimensions fit within your PCB layout constraints. Validate the enable/disable pin configuration before finalizing procurement orders.

Selection Notes

Select this component when a precise 29.4912 MHz clock signal is required for digital circuits. Consider the HCMOS output level for direct interfacing with standard logic gates. Evaluate the enable/disable feature if power conservation during idle states is necessary. Assess the -40°C to +85°C range against environmental conditions. Compare package size against available board space for integration.

Part Context

This oscillator belongs to the 1575H4 series from Suzhou Hangjing Elec&Tech Co.,Ltd. The company specializes in quartz frequency control components, including oscillators and resonators. This series provides standard XO solutions for various electronic applications requiring reliable timing signals.

Replacement Considerations

Consult official manufacturer substitution lists for verified alternatives. Cross-reference electrical parameters such as frequency, voltage, and package type. Verify compatibility with existing circuit designs before replacing.
