1586509

Overview

Phoenix Contact part number 1586509 is a COMBICON series PCB terminal block. It features a 3-pole configuration with a 5.0 mm pitch and black housing. The component utilizes screw connection technology with wire protection for secure wiring. Rated at 400 V and 17.5 A, it supports conductors up to 1.5 mm². Designed for wave soldering mounting, it ensures reliable electrical connections in industrial control applications.

Feature Summary

• Screw connection technology equipped with integrated wire protection mechanisms
• Designed specifically for wave soldering mounting processes on printed circuit boards
• Linear pin layout configuration for standardized board integration

Applications

• Industrial automation control panels
• Signal processing circuits requiring secure PCB termination
• General purpose electronic equipment manufacturing

Procurement Notes

Verify the specific ordering suffix matches the required color and pin configuration. Confirm that the product documentation indicates compliance with relevant safety standards for your region. Ensure compatibility with your assembly process requirements before finalizing procurement orders.

Selection Notes

Select this component when a 3-position terminal with 5.0 mm spacing is required for wave soldering. The screw connection method offers robust mechanical stability compared to spring types. Consider the 1.5 mm² cross-section limit when designing conductor layouts for high-current paths.

Part Context

This component belongs to the Phoenix Contact COMBICON Terminals S product line. It is designed as a fixed connector for direct PCB attachment. The series provides standardized interfaces for signal and power distribution within compact control cabinet environments.

Replacement Considerations

Check for updated versions within the PT 1,5/..-H family. Verify if alternative colors or packaging formats are available from the manufacturer. Ensure any substitute maintains the same pitch and mounting specifications.
