1586513

Overview

The Phoenix Contact part number 1586513 corresponds to the QP 1,5/ 1-L GNYE plug component. This is a single-position terminal plug with a 5.2 mm pitch, designed for quick connection methods. It features a yellow-green color coding and supports wire cross-sections ranging from 0.25 mm² to 1.5 mm². The unit has a rated voltage of 500 V and a nominal current capacity of 17.5 A. Constructed from PA insulation material, it meets UL 94 V0 flammability standards and operates within a temperature range down to -60 °C.

Feature Summary

• Features a left-side plug housing without a safety pin, allowing for open right-side access.
• Utilizes a quick connection technology compatible with rigid and flexible conductors.
• Complies with IEC 61984 standard for COMBI plugs, enabling load-free or voltage-free connection and disconnection.

Applications

• Industrial control cabinet wiring
• Signal distribution systems
• Automation equipment interconnections

Procurement Notes

Verify the specific ordering suffix matches the required configuration, as variations may exist regarding housing orientation or safety pin inclusion. Confirm that the 500 V rating and 17.5 A current capacity align with your circuit requirements. Ensure compatibility with the corresponding COMBICON socket series before procurement.

Selection Notes

Select this component when a single-position, quick-connect solution is required for low-voltage applications. The yellow-green coloring indicates its suitability for protective conductor connections. Consider the 5.2 mm pitch when designing PCB layouts or panel mounting spaces to ensure adequate clearance for adjacent components.

Part Context

This component belongs to the Phoenix Contact COMBICON Terminals S product line. It is designed to interface with matching socket counterparts to form modular connection systems. The series is characterized by compact dimensions and standardized pitches, facilitating dense wiring arrangements in industrial environments.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing socket housings before attempting substitution with other manufacturers' products.

FAQ

Does this plug include a safety pin?

No, the QP 1,5/ 1-L GNYE (1586513) is specified as having a left housing without a safety pin.

What is the maximum wire cross-section supported?

The plug supports a maximum wire cross-section of 1.5 mm² for both rigid and flexible conductors.
