1586877

Overview

The Phoenix Contact part number 1586877 corresponds to the POS POLEFIX M 108 VA, a base support component designed for the Pico Off-Grid system. This unit facilitates pole mounting with a compatible diameter range of 48 mm to 108 mm. It is engineered to accommodate POS-HP enclosure sizes ranging from 204 x 251 mm up to 410 x 455 mm, as well as POS-PV-Panel models in 75, 110, and 190 variants. Constructed from stainless steel, the support ensures durability for outdoor applications. The assembly features a silver finish and includes specific dimensional profiles for angular positions at 30° and 80°, requiring adherence to provided technical drawings for precise installation.

Feature Summary

• Designed specifically for the Pico Off-Grid system infrastructure
• Facilitates secure pole mounting within specified diameter ranges
• Constructed from stainless steel for outdoor environmental resistance
• Compatible with multiple POS-HP and POS-PV-Panel enclosure dimensions

Applications

• Mounting base for Pico Off-Grid system components
• Installation on poles with diameters between 48 mm and 108 mm
• Support structure for POS-HP enclosures and POS-PV-Panel units

Procurement Notes

Verify that the required pole diameter falls within the 48 mm to 108 mm range before procurement. Ensure compatibility with the specific POS-HP or POS-PV-Panel enclosure size intended for installation. Review the official technical drawings available in the download area for accurate dimensional verification. Adhere strictly to the safety instructions regarding moving parts during assembly. Confirm the stainless steel material specification meets environmental requirements.

Selection Notes

Select this model when utilizing the Pico Off-Grid system with standard pole diameters up to 108 mm. Choose this variant over the 1587071 (POLEFIX M 180 VA) if the installation site does not require support for larger poles exceeding 108 mm. Ensure the chosen enclosure fits within the supported POS-HP and POS-PV-Panel size limits. Verify that the stainless steel construction aligns with local corrosion resistance needs.

Part Context

This component belongs to the POS series of outdoor enclosure supports manufactured by Phoenix Contact. It serves as a critical mechanical interface for the Pico Off-Grid energy storage and distribution systems. The product line emphasizes robust mounting solutions for renewable energy applications. The specific model 1586877 addresses mid-range pole diameters, complementing other variants designed for smaller or larger structural requirements within the same ecosystem.

Replacement Considerations

The POS POLEFIX M 180 VA (Part Number 1587071) is a related variant designed for larger pole diameters (75 mm to 180 mm). If the existing pole diameter exceeds 108 mm, the 1587071 model must be used instead. No direct cross-model substitution exists for different pole sizes without verifying mechanical fit. Ensure any replacement maintains the stainless steel construction and POS series compatibility.
