1595440

Overview

Phoenix Contact part number 1595440 is a sensor/actuator cable assembly from the SAC-4P-M 8MSF/2X1,0-93B series. It features a 2-meter length with an unshielded design and a blue polyurethane (PUR) jacket. The cable utilizes four conductors of 1.0 mm² cross-section made from bare copper. It operates within a temperature range of -40°C to 80°C and carries IP67 protection rating for both connectors. Certified standards include UL, cULus, IEC 60332-1-2, EAC, and RoHS compliance. Rated voltage is 24V, with a conductor count of 4 and an outer diameter of 6.4mm.

Feature Summary

• Constructed with durable polyurethane jacketing for high resistance to mechanical wear and industrial chemicals.
• Equipped with M12 straight male connectors on both ends for secure panel mounting and reliable signal transmission.
• Designed with an unshielded configuration suitable for standard sensor and actuator applications.

Applications

• Industrial automation control systems
• Sensor and actuator network connections
• Factory floor wiring environments

Procurement Notes

Verify the specific connector orientation and pin configuration against system requirements before ordering. Confirm that the PUR material properties align with the chemical exposure conditions of the installation site. Ensure the IP67 rating meets the environmental protection needs of the deployment area. Cross-reference the official datasheet for precise torque specifications during installation.

Selection Notes

Select this model when a robust, unshielded connection is required for short-distance sensor networks. The M12 interface ensures compatibility with standard industrial IO-Link and sensor protocols. Consider the operating temperature range and chemical resistance of the PUR jacket for harsh environment suitability.

Part Context

This component belongs to Phoenix Contact's SAC series of pre-wired sensor cables. These assemblies are engineered to provide plug-and-play connectivity in industrial settings, reducing installation time compared to field-wired alternatives. The series emphasizes durability and standardized interfaces for consistent performance across various automation tasks.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.

FAQ

What is the connector type for this cable?

The cable features M12 straight male connectors on both ends.

Is this cable shielded?

No, this specific model is unshielded.
