Product Detailed Parameters
- Description：LINE FLTR 115V/250VAC CHASS MNT
- Series：DR
- Mfr：Delta Electronics
- Package：Box
- Filter Type：Single Phase
- Configuration：Two Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：115V, 250V
- Current：-
- Frequency - Operating：50/60Hz
- Applications：General Purpose
- Approval Agency：CSA, UR, VDE
- Operating Temperature：-
- Mounting Type：Chassis Mount
- Termination Style：Quick Connect
- Inductance：900µH
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The 15DRCG5 is a single-phase EMC/EMI line filter module manufactured by Delta Electronics. It operates at rated AC voltages of 115V and 250V with a frequency range of 50/60Hz. The component features a two-stage configuration and utilizes quick connect terminals for circuit attachment. Designed for chassis mounting, it serves general purpose applications requiring electromagnetic interference suppression in power line systems.
Feature Summary
- Single-phase EMC/EMI filtering capability
- Two-stage attenuation configuration
- Chassis mount installation style
- Quick connect terminal interface
Applications
- General purpose power line filtering
- EMC compliance in electronic equipment
- Industrial control system power inputs
Procurement Notes
Verify the current lifecycle status before procurement as end-of-life notifications may apply to this model. Confirm that the chassis mounting requirements and quick connect terminal specifications align with the target enclosure design. Ensure the rated voltage and current parameters meet the specific application needs. Check for any recent product change notices or alternative part recommendations from the manufacturer.
Selection Notes
Select this component when single-phase EMI suppression is required for 115V or 250VAC systems. The two-stage design offers enhanced noise reduction compared to single-stage alternatives. Consider the chassis mounting constraint during mechanical design. Verify that the quick connect terminals are compatible with the available wiring harnesses or PCB footprints in the final assembly.
Part Context
This model belongs to Delta Electronics' power line filter module series. These components are designed to suppress conducted electromagnetic interference in AC power lines. The series typically includes various ratings for different current and voltage applications, maintaining consistent mounting and connection styles across the family for design flexibility.
