1602497

Overview

Phoenix Contact part number 1602497 is a circular metric cable connector belonging to the RC-19P1N121700 series. It features an M23 screw locking mechanism and a PG13.5 connection thread. The connector provides 19 positions, configured as 16+3 contacts. It utilizes pin-type contacts with Ni/Au surface plating for signal applications. The unit weighs 31.210 g and supports 100 insertion cycles.

Feature Summary

• Equipped with a standard screw locking mechanism for secure attachment.
• Designed for signal transmission applications using pin-type contacts.
• Features Ni/Au contact surface plating for reliable conductivity.

Applications

• Industrial signal wiring
• Circular connector assemblies
• Control cabinet interconnections

Procurement Notes

Verify the specific suffix and configuration against official Phoenix Contact datasheets before ordering. Confirm that the PG13.5 thread and 16+3 position count match your system requirements. Check current availability status as supply may be restricted in certain regions. Ensure compatibility with mating connectors regarding shielding and locking type.

Selection Notes

Select this model when a straight cable connector with M23 screw locking is required. The 16+3 position layout suits systems needing additional auxiliary signals. Verify that the PG13.5 strain relief fits your cable diameter. Consider the 100-cycle durability rating for maintenance frequency.

Part Context

This component is part of the PLUSCON Circular family from Phoenix Contact. It serves as a robust solution for industrial environments requiring reliable signal connectivity. The M23 size offers a balance between compactness and contact density for control applications.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Consult manufacturer guidelines for cross-referencing alternatives if this specific configuration is unavailable.

FAQ

What is the contact configuration for part 1602497?

The connector has 19 positions arranged in a 16+3 configuration.

Does this connector support shielding?

According to specifications, this specific cable connector is not shielded.
