1623165

Overview

Phoenix Contact part number 1623165 is a PCB plug-in connector from the FMC 1,5/ 6-STF-3,81 series. It features a 6-pole configuration with a 3.81 mm pitch and supports a rated current of 10 A at a nominal voltage of 320 V. The component utilizes spring-cage connection technology for wire termination, accommodating rigid conductors within a cross-section range of 0.08 mm² to 1.5 mm². Designed for surface mounting on printed circuit boards, it provides reliable electrical interconnection in industrial environments.

Feature Summary

• Utilizes spring-cage connection technology for secure wire termination without screws
• Designed for direct surface mounting onto printed circuit boards
• Provides standardized 3.81 mm pitch spacing for compact circuit layouts

Applications

• Industrial control cabinet wiring
• Signal distribution in automation systems
• Machine tool electrical connections

Procurement Notes

Verify the specific ordering suffix against the official Phoenix Contact datasheet to ensure correct packaging and variant selection. Confirm that the 3.81 mm pitch and 6-pole count match the design requirements. Cross-reference the manufacturer's documentation for RoHS compliance status and storage conditions prior to procurement.

Selection Notes

Select this component when a low-profile PCB connector with spring-cage termination is required. Ensure the application voltage does not exceed 320 V and the current load remains within the 10 A rating. Verify that the available board space accommodates the 3.81 mm pitch and that the wire gauge falls within the 0.08 mm² to 1.5 mm² acceptance range.

Part Context

This connector belongs to the FMC series of PCB plug-in terminals manufactured by Phoenix Contact. The series is characterized by its compact design and robust spring-cage technology, intended for high-density signal and power distribution in industrial automation and control engineering applications.

Replacement Considerations

Consult the Phoenix Contact cross-reference search for verified alternatives. Ensure any substitute maintains the identical 3.81 mm pitch, 6-pole count, and spring-cage termination mechanism to guarantee mechanical and electrical compatibility.
