16AYC10B

Overview

The 16AYC10B is a single-stage RFI power line filter from the AYC series, manufactured by TE Connectivity Corcom Filters. It is designed for three-phase, four-wire WYE applications in high-noise industrial environments. The unit features a chassis mount style with stud termination and supports a rated current of 16 A at voltages up to 480 V. Operating at 50 Hz or 60 Hz, it exhibits a leakage current of 700 uA. The component holds UL certification and is identified by part number alias 6609067-1.

Feature Summary

• Engineered specifically for three-phase, four-wire WYE configurations in noisy industrial wiring setups
• Provides effective EMI/RFI attenuation suitable for sensitive equipment like frequency converters
• Utilizes robust chassis mount construction with stud termination for secure installation

Applications

• Frequency converter installations
• Industrial machinery with high electrical noise
• Three-phase power distribution systems requiring EMI suppression

Procurement Notes

Verify the specific datasheet version corresponding to part number 16AYC10B or its alias 6609067-1 to confirm mechanical dimensions and terminal specifications. Ensure compatibility with the target chassis mounting hole pattern and stud size. Cross-reference the 480 V rating and 16 A current capacity against the actual load requirements. Confirm UL certification status if required for the final assembly compliance.

Selection Notes

Select this model when a single-stage solution is sufficient for three-phase WYE systems. It is appropriate where chassis mounting is preferred over panel mounting. Consider the 16 A current limit and 480 V maximum voltage during circuit design. Evaluate if the specified leakage current meets safety isolation requirements for the connected loads.

Part Context

This component belongs to the AYC series of power line filters, which are specialized for industrial EMC/EMI suppression. The series focuses on handling high-noise environments typical in heavy industry. TE Connectivity Corcom Filters produces this line to address stringent electromagnetic interference standards in three-phase power applications.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify mechanical fit and electrical ratings before considering alternative manufacturers.
