Product Detailed Parameters
- Description：LINE FILTER 480VAC CHASSIS MOUNT
- Series：TYT
- Mfr：Delta Electronics
- Package：Box
- Filter Type：Three Phase (Wye)
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：480V
- Current：-
- Frequency - Operating：50/60Hz
- Applications：General Purpose
- Approval Agency：-
- Operating Temperature：-
- Mounting Type：Chassis Mount
- Termination Style：Terminal Block
- Inductance：1.2mH
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The Delta Electronics 16TYT8 is a high-performance three-phase, four-wire power line filter designed for chassis mounting. It features a single-stage configuration with a rated AC voltage of 480V and a current rating of 16A. The component utilizes terminal block connections for secure installation. This filter is engineered to suppress electromagnetic interference in industrial power systems, ensuring compliance with EMC standards while maintaining stable operation under specified electrical loads.
Feature Summary
- High-performance filtering for three-phase power lines
- Chassis mount design with terminal block connections
- Engineered for electromagnetic interference suppression
Applications
- Industrial machinery power conditioning
- Three-phase motor drive protection
- Factory automation control panels
Procurement Notes
Verify the specific suffix (e.g., -1, -2) against the required voltage rating and connection type, as variants exist within the TYT series. Confirm RoHS3 compliance status if environmental regulations apply. Ensure chassis mounting dimensions and terminal block spacing match the enclosure design before procurement.
Selection Notes
Select this model for applications requiring 480VAC three-phase filtering at 16A. Consider the 16TYT8-1 variant if a 520VAC rating is necessary. Evaluate space constraints for chassis mounting and verify that terminal block termination suits the wiring gauge. Compare attenuation requirements against datasheet curves to ensure adequate noise reduction.
Part Context
This component belongs to the Delta Electronics TYT series of power line filters. The series offers various configurations for three-phase applications, including different voltage ratings and stage counts. The 16TYT8 represents the standard 480VAC, 16A single-stage option within this lineup.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing enclosures and wiring terminals when considering alternative models from other manufacturers.
