1714H-48.000G50DTSTK

Overview

The 1714H-48.000G50DTSTK is a standard crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a frequency of 48.000 MHz and utilizes HCMOS output logic levels. The device is powered by a 5V supply voltage and housed in a 9x14 mm surface-mount package with six no-lead solder pads. It features a frequency stability of ±50 ppm over the operating temperature range.

Feature Summary

• Generates a precise 48 MHz clock signal using HCMOS technology
• Operates reliably on a single 5V power supply
• Provides stable frequency performance within specified temperature limits

Applications

• General-purpose digital timing circuits
• Microcontroller clock sources
• Industrial control systems requiring standard frequency references

Procurement Notes

Verify the specific ordering suffix to confirm the exact frequency, voltage, and package dimensions match your design requirements. Ensure the supplier provides official documentation from Suzhou Hangjing Elec&Tech Co., Ltd. to guarantee component authenticity and technical accuracy for integration.

Selection Notes

Select this component when a 48 MHz clock source with HCMOS compatibility is required. Confirm that the 5V supply voltage aligns with your system architecture. Evaluate the ±50 ppm stability against your application's timing tolerance requirements before finalizing the part choice.

Part Context

This model belongs to the 1714H series of quartz oscillators produced by Suzhou Hangjing. The series focuses on providing robust frequency control solutions for computing, communication, and industrial applications. The manufacturer specializes in research and production of quartz frequency controlling units since 2014.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided data. Verify pinout and electrical specifications carefully if considering alternative manufacturers.
